hEX S (2025)

hEX S (2025)

hEX S (2025)

Router wired kompak dan hemat biaya dari MikroTik terbaru. Port SFP 2.5G, 5x Gigabit Ethernet, PoE-in dan PoE-out, USB 3.0, dan dual-core CPU — solusi jaringan kabel andal untuk rumah, kantor, maupun lab.

Fitur Lengkap
011x port SFP 2.5G — uplink fiber berkecepatan tinggi untuk koneksi backbone atau ISP tanpa bottleneck
025x port Gigabit Ethernet — setiap port dapat dikonfigurasi bebas sebagai WAN, LAN, atau bridge sesuai kebutuhan
03PoE-in di port #1 (802.3af/at) dan PoE-out pasif di port #5 — fleksibel untuk mensuplai daya ke kamera IP atau access point
04Dual-core ARM CPU 950 MHz + 512 MB RAM — performa cepat untuk routing, VPN, firewall, dan fitur RouterOS tingkat lanjut
05IPsec hardware encryption — tunnel VPN aman dengan throughput tinggi tanpa membebani CPU secara berlebihan
06USB 3.0 full-size — untuk storage eksternal, modem LTE, atau keperluan logging dan file sharing lokal
07RouterOS v7 License Level 4 — VLAN, bonding, traffic shaping, OSPF, BGP, hotspot, NAT, dan DHCP siap pakai
08Form factor kompak dan bisa dipasang di dinding — mudah diinstalasi di rumah, kantor kecil, maupun lab jaringan


Specification

Specifications
  • Product codeE60iUGS
  • Suggested price$-
  • ArchitectureARM 32bit
  • CPUEN7562CT
  • CPU core count2
  • CPU nominal frequency950 MHz
  • CPU Threads count2
  • Switch chip modelEN7523
  • RouterOS license4
  • Operating SystemRouterOS v7
  • Size of RAM512 MB
  • Storage size128 MB
  • Storage typeNAND
  • MTBFApproximately 100'000 hours at 25C
  • Tested ambient temperature-40°C to 70°C
Powering
  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage12-57 V
  • Max power consumption23 W
  • Max power consumption without attachments5 W
  • PoE in802.3af/at
  • Cooling typePassive
  • PoE in input Voltage18-57 V
PoE-out
  • PoE-out portsEther5
  • PoE outPassive PoE up to 57V
  • Low voltage PoE-Out current limit0.5 A
  • High voltage PoE-Out current limit0.5 A
Ethernet
  • 10/100/1000 Ethernet ports5
  • Number of 1G Ethernet ports with PoE-out1
Fiber
  • SFP ports1 (2.5G supported)
Peripherals
  • Number of USB ports1
  • USB Power ResetYes
  • USB slot typeUSB 3.0 type A
  • Max USB current (A)1
Other
  • CPU temperature monitorYes
  • PCB temperature monitorYes
  • Voltage MonitorYes
  • Mode buttonYes
Certification & Approvals
  • CertificationCE, EAC, ROHS
  • IP20
Included parts
Note
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
