PWR-LINE AP (US plug) / PL6411-2nD

The PWR-Line AP is a small Wi-Fi access point, made as an accessory to your existing network, for places, where your signal or your cable is unable to reach. Unit comes with Type A power plug (commonly used in USA, Canada, Mexico & Thailand)

Especially useful in homes with thick walls, where you can extend Wi-Fi coverage to those rooms, where signal is poor, without having to re-wire your house.

Simply plug this device directly into one of the LAN ports of your MikroTik router, and add another one somewhere further in your premises. They will link together through the power lines. You can install up to eight PWR-LINE devices to further build your network.



Product specifications

Details
Product code PL6411-2nD
10/100 Ethernet ports 1
Antenna gain dBi for 2.4 GHz 1.5
Architecture MIPSBE
CPU QCA9533
CPU core count 1
CPU nominal frequency 650 MHz
Can be used indoors Yes
Certification CE/RED, FCC, IC, EAC, ROHS
Dimensions 50 x 68 x 33mm
License level 4
Max power consumption 6.3 W
Operating System RouterOS
PLC chipset QCA6410
Size of RAM 64 MB
Storage size 16 MB
Storage type FLASH
Tested ambient temperature -20°C to 60°C
Wi-Fi generation Wi-Fi 4
Wireless 2.4 GHz Max data rate 300 Mbit/s
Wireless 2.4 GHz chip model QCA9533
Wireless 2.4 GHz generation Wi-Fi 4
Wireless 2.4 GHz number of chains 2
Wireless 2.4 GHz standards 802.11b/g/n
Suggested price $42



Wireless specifications

2.4 GHzTransmit (dBm)Receive Sensitivity
1MBit/s22-96
11MBit/s22-89
6MBit/s20-93
54MBit/s18-74
MCS020-93
MCS716-71
