RB5009UG+S+IN

RB5009UG+S+IN

RB5009UG+S+IN

Heavy-duty RouterBOARD dari MikroTik dengan CPU quad-core ARMv8 1.4 GHz, 7x Gigabit Ethernet, 1x 2.5G Ethernet, dan 1x 10G SFP+ — performa dua kali lipat dalam form factor kompak yang bisa dipasang 4 unit dalam 1U rack.

FITUR LENGKAP

011x port 10G SFP+ — koneksi uplink ultra-cepat untuk backbone fiber, agregasi, atau koneksi ke switch core 10 Gigabit
027x port Gigabit Ethernet + 1x port 2.5G Ethernet — total 9 port kabel untuk kebutuhan LAN, WAN, dan koneksi perangkat server
03CPU Marvell Armada quad-core ARMv8 1.4 GHz + switch-chip Marvell Amethyst — jalur 10 Gbps full-duplex antara switch dan CPU tanpa bottleneck
041 GB DDR4 RAM + 1 GB NAND storage — kapasitas memori dan penyimpanan dua kali lipat dibanding router MikroTik form factor sejenis
053 opsi power input: PoE-in port #1, DC Jack, dan 2-pin terminal 24–57V DC — fleksibel untuk berbagai skenario instalasi dan redundansi daya
061x USB 3.0 full-size Type-A — untuk storage eksternal, backup konfigurasi, atau modem USB sebagai koneksi WAN cadangan
07Desain heatsink pasif — CPU dan switch-chip terpasang di bawah board sehingga casing bertindak sebagai pendingin masif tanpa kipas bising
08RouterOS v7 License Level 5 — mendukung firewall canggih, VPN (WireGuard, IPsec, OpenVPN), BGP, OSPF, MPLS, dan manajemen bandwidth penuh



Specification

Specifications
  • Product codeRB5009UG+S+IN
  • Suggested price$-
  • ArchitectureARM 64bit
  • CPU88F7040
  • CPU core count4
  • CPU nominal frequency350-1400 (auto) MHz
  • CPU Threads count4
  • Switch chip model88E6393
  • Dimensions220 x 125 x 22 mm
  • RouterOS license5
  • Operating SystemRouterOS v7
  • Size of RAM1 GB
  • Storage size1 GB
  • Storage typeNAND
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-40°C to 60°C
Powering
  • Number of DC inputs3 (DC jack, PoE-IN, 2-pin terminal)
  • DC jack input Voltage24-57 V
  • 2-pin terminal input Voltage24-57 V
  • Max power consumption25 W
  • Max power consumption without attachments14 W
  • PoE in802.3af/at
  • Cooling typePassive
  • PoE in input Voltage24-57 V
Ethernet
  • 10/100/1000 Ethernet ports7
  • Number of 2.5G Ethernet ports1
Fiber
  • SFP+ ports1
Peripherals
  • Number of USB ports1
  • USB Power ResetYes
  • USB slot typeUSB 3.0 type A
  • Max USB current (A)1.5
Other
  • CPU temperature monitorYes
Certification & Approvals
  • CertificationCE, EAC, ROHS
Included parts
Note
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
