Specification

Specifications

• Product codeE62iUGS-2axD5axT
• Suggested price-
• ArchitectureARM 32bit
• CPUEN7562CT
• CPU core count2
• CPU nominal frequency950 MHz
• CPU Threads count2
• Switch chip modelEN7523
• RouterOS license4
• Operating SystemRouterOS v7
• Size of RAM512 MB
• Storage size128 MB
• Storage typeNAND
• MTBFApproximately 100'000 hours at 25C
• Tested ambient temperature-40°C to 70°C

Wireless capabilities

• Wireless 2.4 GHz Max data rate574 Mbit/s
• Wireless 2.4 GHz Number of chains2
• Wireless 2.4 GHz standards802.11b/g/n/ax
• Antenna gain dBi for 2.4 GHz5.5
• Wireless 2.4 GHz chip modelMT7916
• Wireless 2.4 GHz generationWi-Fi 6
• Wireless 5 GHz Max data rate2400 Mbit/s
• Wireless 5 GHz Number of chains3
• Wireless 5 GHz standards802.11a/n/ac/ax
• Antenna gain dBi for 5 GHz6.5
• Wireless 5 GHz chip modelMT7976
• Wireless 5 GHz generationWi-Fi 6
• WiFi speedAX3000

Ethernet

• 10/100/1000 Ethernet ports5
• Number of 1G Ethernet ports with PoE-out1

Fiber

• SFP ports1 (2.5G supported)

Peripherals

• Number of USB ports1
• USB Power ResetYes
• USB slot typeUSB type A
• Max USB current (A)1

Powering

• Number of DC inputs2 (DC jack, PoE-IN)
• DC jack input Voltage12-28 V
• Max power consumption34 W
• Max power consumption without attachments11 W
• PoE inPassive PoE
• Cooling typePassive
• PoE in input Voltage18-28 V

PoE-out

• PoE-out portsEther5
• PoE outPassive PoE
• Low voltage PoE-Out current limit0.6 A
• Max total out (A)0.6 A
• Total output current0.6
• Total output power16.8

Certification & Approvals

• CertificationCE, FCC, IC, EAC, ROHS
• IP20

Other

• CPU temperature monitorYes

Included parts

24V 1.5A power adapter

Note

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
