Wireless Access Point Wi-Fi 7 terbaru dari MikroTik. CPU quad-core ARM, 802.11be tri-band dengan Multi-Link Operation (MLO), 2x port 2.5G Ethernet — solusi Wi-Fi rumahan dan kantor kecil yang terjangkau namun bertenaga penuh.

FITUR LENGKAP

01Wi-Fi 7 (802.11be) tri-band — 2.4 GHz + 5 GHz + 6 GHz untuk throughput agregat hingga 5.8 Gbps
022x port 2.5G Ethernet — WAN dan LAN berkecepatan tinggi tanpa bottleneck di sisi kabel
03Multi-Link Operation (MLO) — menggabungkan beberapa band sekaligus untuk latensi rendah dan stabilitas koneksi maksimal
04CPU quad-core ARM 1.7 GHz + 1 GB RAM — performa routing dan firewall memadai untuk koneksi ISP modern
05RouterOS v7 License Level 4 — kontrol penuh atas routing, firewall, VPN, QoS, dan manajemen jaringan tanpa biaya tambahan
06PoE-in via port Ethernet — instalasi fleksibel tanpa kabel power tambahan jika tersedia injector PoE
07Desain compact dan mountable — mudah dipasang di dinding atau langit-langit tanpa memerlukan ruang perangkat tambahan
08WPA3 + PMF + enkripsi terkini — keamanan jaringan wireless kelas enterprise untuk rumahan maupun kantor kecil

Specification

Specifications
  • Product codeMA53UG+HbeH
  • Suggested price$-
  • ArchitectureARM 64bit
  • CPUIPQ-5322
  • CPU core count4
  • CPU nominal frequencyUp to 1.5 GHz (auto)
  • CPU Threads count4
  • Switch chip modelQCA8386
  • RouterOS license6
  • Operating SystemRouterOS v7
  • Size of RAM2 GB
  • Storage size512 MB
  • Storage typeNAND
  • MTBFApproximately 200'000 hours at 25C
  • Tested ambient temperature-30°C to 50°C
Wireless capabilities
  • Wireless 2.4 GHz Max data rate574 Mbit/s
  • Wireless 2.4 GHz Number of chains2
  • Wireless 2.4 GHz standards802.11b/g/n/ax/be
  • Antenna gain dBi for 2.4 GHz4
  • Wireless 2.4 GHz chip modelIPQ-5322
  • Wireless 2.4 GHz generationWi-Fi 7
  • Wireless 5 GHz Max data rate1200 Mbit/s
  • Wireless 5 GHz Number of chains2
  • Wireless 5 GHz standards802.11a/n/ac/ax/be
  • Antenna gain dBi for 5 GHz7.5
  • Wireless 5 GHz chip modelQCM-8083
  • Wireless 5 GHz generationWi-Fi 7
  • WiFi speedAX1800
  • Wireless 6 GHz Max data rate5764 Mbit/s
  • Wireless 6 GHz Number of chains2
  • Wireless 6 GHz standards802.11ax/be
  • Antenna gain dBi for 6 GHz8
  • Wireless 6 GHz chip modelQXM-8086
  • Wireless 6 GHz generationWi-Fi 7
Ethernet
  • Number of 2.5G Ethernet ports5
Peripherals
  • Number of USB ports3
  • USB slot typeUSB 3.0 type A
  • Max USB current (A)1.5
Powering
  • Number of DC inputs2 (DC jack, PoE-IN)
  • DC jack input Voltage24-57 V
  • Max power consumption29 W
  • Max power consumption without attachments20 W
  • PoE in802.3af/at
  • Cooling typePassive
  • PoE in input Voltage24-57 V
Certification & Approvals
  • CertificationCE, FCC, IC, EAC, ROHS
  • IP20
Other
  • CPU temperature monitorYes
  • Bluetooth version5.4
Included parts
Note
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
