Forget about CPU limitations in 10G setups with this powerful 16-core
ARM CPU based CCR. Double the performance of our previous 36-
core CCR, 6x faster BGP performance. Includes an M.2 PCIe slot.
Specifications
| Details |
| Product code |
CCR2116-12G-4S+ |
| Architecture |
ARM 64bit |
| CPU |
AL73400 |
| CPU core count |
16 |
| CPU nominal frequency |
2000 MHz |
| RouterOS license |
6 |
| Operating System |
RouterOS (v7 only) |
| Size of RAM |
16 GB |
| Storage size |
128 MB |
| Storage type |
NAND |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-20°C to 60°C |
|
|
Powering
| Details |
| Number of AC inputs |
2 |
| AC input range |
100-240 |
| Max power consumption |
72 W |
| Max power consumption without attachments |
60 W |
| Cooling type |
4 |
Ethernet
| Details |
| 10/100/1000 Ethernet ports |
13 |
Fiber
Peripherals
| Details |
| Serial console port |
RJ45 |
| Number of M.2 slots |
1 |
Other
| Details |
| CPU temperature monitor |
Yes |
| PCB temperature monitor |
Yes |
| Mode button |
Yes |
Certification & Approvals
| Details |
| Certification | CE, EAC, ROHS |
